Output capacity:5HL(500L)
Heating method:steam, electricity or direct fire;
Area request:50㎡
Building height requirement:3.5m
Power supply:Single Phase/ 220(110, 240…)v/50(60)Hz
3phase/380(220, 415,440…)v/50 (60)Hz
1.WEMAC supply beer brewing system with turn-key project.
2.WEMAC provide beer equipment with free consultation,3D design,free installation,training.
3.Three years warranty for the main equipment and spare parts.
4.WEMAC beer machine brew different flavors of beer and brew several flavors of beer at the same time.
5.WEMAC beer machine has beautiful appearance, it is convenient for customer visiting.
Widely used in bars, hotels, beer houses, restaurants, clubs, schools, laboratories, farm brewery and so on.
Output capacity:5HL(500L)
Heating method:steam, electricity or direct fire;
Area request:50㎡
Building height requirement:3.5m
Power supply:Single Phase/ 220(110, 240…)v/50(60)Hz
3phase/380(220, 415,440…)v/50 (60)Hz
Note: 1HL=100liter; 1Gallon=3.7854liter; 1BBL(Barrel ) =117Liter
| Milling system | Stainless steel or carbon steel malt mill Flexible or stainless steel screw conveyor |
| Mash system | Material:SUS316L, SUS304,copper; Mash & kettle& lauter & whirlpool tun are any combination;dimple jacket or dribbling for heat exchanger, rock wool insulation,TH=80-100mm,upper stirring or bottom stirring,lauter plate:milling,side or bottom vinasse discharging Hot liquid tank for option; Plate heat exchanger: cooling form,capacity and piping meet requirements; Oxygenation system:oxygenation form, capacity and interface form meet requirement; Yeast adding tank depends on the customer’s requirement; Stainless steel working platform; Accessories:wort pump, wort tester, hop adding device,hop filter device, saccharimeter,worst rake,CIP system etc |
| Fermentation system | 5HL(500L) / 10HL(1000L) fermentation tank 5HL(500L) / 10HL(1000L) beer brite tank Amount depends on the customer's request Dimple jacket or dribbling cooling Option:dry hop mouth,CO2 filling device with titanium rod distributor,level gauge |
| CIP | Mobile or Fixed CIP |
| Energy system | Heating system &cooling system design capacity meet the requirement |
| Electric system | Stainless steel electric cabinet with imported brand PLC and touch screen or spraying plastics electric cabinet with push-button |
| Pipeline fittings system | Including mash line, alcohol water line and other system line,valves |
| Filtering and sterilization system | Candle type diatomite filter and pasteurizer |
| Beer distribution | To bar wine column Keg washing&filling machine Bottle brushing&filling machine Can filling machine Label machine |
